Home Accessories RPLT series
LED1W-W

Specifications

Lighting specifications
Light color, peak wavelength white, 6000 K
Spectral FWHM (nm) -
Electrical specifications
LED forward voltage typical (max) (1) (V) 2.8 (-)
Max LED forward current (2) (mA) 350
Max pulse current (3) (mA) 2000
Mechanical specifications
Length (mm) 21.0
Width (mm) 21.0
Height (mm) 3.6
Mass (g) 2
Environmental specifications
Operating temperature (°C) 0-40
Storage temperature (°C) 0-50
Operating relative humidity (%) 20-85, non condensing
Installation Indoor use only
Compatible products
Compatible products LTSCHPxW-x, LTSCCPxW-x

Last update 18 Nov 2022

CE
ROHS
REACH
WEEE
UKCA

Notes

  1. At max forward current. Tolerance is ± 0.06V on forward voltage measurements
  2. In continuous mode (not pulsed)
  3. At pulse width <= 10 ms and duty cycle <= 10%. Built-in electronics board must be bypassed (see tech info)
All product specifications and data are subject to change without notice to improve reliability, functionality, design or other. Photos and pictures are for illustration purposes only.
Required field
Required field
Required field
Required field
Required field
Required field
Required field
Required field
Minimun length: 6 characters
Required field
Required field

Compatible products

Despite the efforts made to generate an error-free compatibility list, we always recommend to consult the Opto Engineering® technical support department before purchasing a compatible product. Opto Engineering® shall not be liable for any damage or malfunctioning caused by the incorrect selection of a compatible product.
LTCL4K060-W
Telecentric illuminator for line scan cameras, beam dimension {beam_shape_dimensions} mm, white, 6000 K
LTCL4K090-W
Telecentric illuminator for line scan cameras, beam dimension {beam_shape_dimensions} mm, white, 6000 K
LTCL4K120-W
Telecentric illuminator for line scan cameras, beam dimension {beam_shape_dimensions} mm, white, 6000 K
LTCL4K180-W
Telecentric illuminator for line scan cameras, beam dimension {beam_shape_dimensions} mm, white, 6000 K
LTCLCR048-W
Telecentric CORE illuminator, beam dimensions Ø = 56, x = 50, white, 6000 K
LTCLCR056-W
Telecentric CORE illuminator, beam dimensions Ø = 74, x = 66, white, 6000 K
LTCLCR064-W
Telecentric CORE illuminator, beam dimensions Ø = 86, x = 67, white, 6000 K
LTCLCR080-W
Telecentric CORE illuminator, beam dimensions Ø = 98, x = 90, white, 6000 K
LTCLCR096-W
Telecentric CORE illuminator, beam dimensions Ø = 120, x = 99, white, 6000 K
LTCLHP023-W
Telecentric HP illuminator, beam diameter 16 mm, white, 6000 K
LTCLHP016-W
Telecentric HP illuminator, beam diameter 20 mm, white, 6000 K
LTCLHP024-W
Telecentric HP illuminator, beam diameter 30 mm, white, 6000 K
LTCLHP036-W
Telecentric HP illuminator, beam diameter 45 mm, white, 6000 K
LTCLHP048-W
Telecentric HP illuminator, beam diameter 60 mm, white, 6000 K
LTCLHP056-W
Telecentric HP illuminator, beam diameter 70 mm, white, 6000 K
LTCLHP064-W
Telecentric HP illuminator, beam diameter 80 mm, white, 6000 K
LTCLHP080-W
Telecentric HP illuminator, beam diameter 100 mm, white, 6000 K
LTCLHP096-W
Telecentric HP illuminator, beam diameter 120 mm, white, 6000 K
LTCLHP120-W
Telecentric HP illuminator, beam diameter 150 mm, white, 6000 K
LTCLHP192-W
Telecentric HP illuminator, beam diameter 250 mm, white, 6000 K
LTSCHP1W-W
Replacement LED module, white
