Main optical specifications | ||
Focal length | (mm) | 5 |
Magnification (1) | (x) | 0.043 |
Image circle diameter | (mm) | 8.0 |
Max sensor size | 1/2″ |
Angle of view | ||
1/3” | (deg) | 62.3 |
1/2” | (deg) | 76.7 |
2/3” | (deg) | - |
Object field of view | ||
1/3” (1) | 111.63 x 83.72 | |
1/2” (1) | 148.84 x 111.63 | |
2/3” (1) | - |
Advanced optical specifications | ||
Working distance range (2) | (m) | 0.1 - inf |
ƒ/N | 1.4 - 16 | |
Back focal length | (mm) | 10.8 |
Distortion on 1/3" (3) | (%) | 2.26 |
Distortion on 1/2" (3) | (%) | 0.48 |
Distortion on 2/3" (3) | (%) | - |
Mechanical specifications | ||
Iris control | Manual | |
Focus control | Manual | |
Mount | C | |
Filter thread | M43 x 0.75 | |
Outer diameter | (mm) | 44.5 |
Length (4) | (mm) | 45.5 |
Mass | (g) | 102 |
Last update 02 Aug 2023
Notes
- Calculated at minimum object distance.
- Working distance: distance between the front end of the mechanics and the object.
- Value calculated at the corner point of the sensor diagonal. For distortion graphs see datasheet
- Measured from the front end of the mechanics to the camera flange at infinite focusing.
All product specifications and data are subject to change without notice to improve reliability, functionality, design or other. Photos and pictures are for illustration purposes only.
Datasheet
Download datasheet
Layout files
DXF
IGS
PDF
STP
Despite the efforts made to generate an error-free compatibility list, we always recommend to consult the Opto Engineering® technical support department before purchasing a compatible product. Opto Engineering® shall not be liable for any damage or malfunctioning caused by the incorrect selection of a compatible product.
ITA24-GC-10C
Area scan camera 1936 x 1216 MP, Sony IMX392, CMOS Global shutter, 1/2.3", Color, 1 GigE, POE, C mount
ITA24-GM-10C
Area scan camera 1936 x 1216 MP, Sony IMX392, CMOS Global shutter, 1/2.3", Mono, 1 GigE, POE, C mount
ITA32-GM-10C
Area scan camera 2064 x 1544 MP, Sony IMX265, CMOS Global shutter, 1/1.8", Mono, 1 GigE, POE, C mount
ITA32-GC-10C
Area scan camera 2064 x 1544 MP, Sony IMX265, CMOS Global shutter, 1/1.8", Color, 1 GigE, POE, C mount
ITA51-GM-20C
Area scan camera 2472 x 2064 MP, Sony IMX547, CMOS Global shutter, 1/1.8", Mono, 1 GigE, POE, C mount
ITA51-GC-20C
Area scan camera 2472 x 2064 MP, Sony IMX547, CMOS Global shutter, 1/1.8", Color, 1 GigE, POE, C mount
FTBP470M43
Optical filter, band pass, blue
FTBP525M43
Optical filter, band pass, green
FTBP635M43
Optical filter, band pass, red
FTBP660M43
Optical filter, band pass, dark red
FTBP850M43
Optical filter, band pass, IR
FTSP450M43
Optical filter, short pass, dark blue
FTSP500M43
Optical filter, short pass, blue
FTSP570M43
Optical filter, short pass, cyan
FTSP700M43
Optical filter, UV+NIR cut off, VIS
FTLP510M43
Optical filter, long pass, yellow
FTLP550M43
Optical filter, long pass, orange
FTLP590M43
Optical filter, long pass, red
FTLP640M43
Optical filter, long pass, dark red
