FTSP570M43
Specifications
Downloads
Compatible products
Main optical specifications
Type short pass
Light color cyan
Wavelength range (nm) 330 - 575
Cut-on 50% transmittance (1) (nm) -
Cut-off 50% transmittance (1) (nm) 575
Spectral FWHM (1) (nm) -
Mechanical specifications
Filter thread M43 x 0.75
Outer diameter (mm) 46.0
Clear aperture (mm) 38.0

Last update 20 Oct 2023

REACH

Notes

  1. Tolerance +/- 10 nm
All product specifications and data are subject to change without notice to improve reliability, functionality, design or other. Photos and pictures are for illustration purposes only.

Technical documents

Product user guide

Datasheet

Download datasheet
Despite the efforts made to generate an error-free compatibility list, we always recommend to consult the Opto Engineering® technical support department before purchasing a compatible product. Opto Engineering® shall not be liable for any damage or malfunctioning caused by the incorrect selection of a compatible product.
RT-H0514-MP2
Megapixel lens, focal length 5 mm, f/N 1.4 - 16, C-mount
