LT2PRUP-UV405
Specifications
Downloads
Compatible products
Lighting specifications
Active area diameter (mm) 17.6
Light color, peak wavelength UV, 405 nm
Spectral FWHM (nm) 25
Illuminance (continuous) (1) (klux) 35
Irradiance (continuous) (1) (W/m2) 15500
Illuminance (strobe) (1) (klux) 45
Irradiance (strobe) (1) (W/m2) 26500
Electrical specifications
Operating mode Continuous and strobe
Supply voltage (2) (V) 24
Current (2) (A) 2.6
Power consumption (2) (W) 62.4
Peak power consumption (3) (W) 115.2
Max LED forward current (3) (A) 3.0
Min pulse duration (µs) 2
Max pulse duration (ms) 10
Max duty-cycle (%) 10
Typical pulse delay (ns) 400
Typical jitter (ns) 100
I/O interface PNP logic input, NPN logic input, analog dimming input
Connector 1x M12 straight plug male connector
Cables not inluded
Mechanical specifications
Mount C
Phase adjustment Yes
Length (mm) 118.5
Width (mm) 77.3
Height (mm) 77.3
Mass (g) 530
Environmental specifications
Operating temperature (°C) 0-40
Storage temperature (°C) 0-50
Operating relative humidity (%) 20-85, non condensing
Installation Indoor use only
IP rating IP30
Eye safety
Risk group according to CEI EN 62471:2010 Risk group 3

Last update 01 Jul 2024

CE
FCC
UKCA
ROHS
REACH
WEEE

Notes

  1. At pattern emitting surface.
  2. Continuous mode, using the integrated electronic driver.
  3. Strobe mode.
  4. Max duty cycle can be lowered by the device depending on pulse duration and frequency.
All product specifications and data are subject to change without notice to improve reliability, functionality, design or other. Photos and pictures are for illustration purposes only.

Technical documents

LT2PR Manual

Datasheet

Download datasheet

Layout files

DXF
IGS
PDF
STEP
SLDPRT
