Specifications
Downloads
Compatible products
| Main optical specifications | ||
| Focal length | (mm) |
- - |
| Magnification | (x) |
0.084 0.840 |
| Image circle diameter | (mm) |
8 8 |
| Max sensor size |
1/2″ 1/2″ |
|
| Angle of view | ||
| 1/2” | (deg) |
21.6 4.5 |
| 2/3” | (deg) |
- - |
| Object field of view | ||
| 1/2” |
76.19 x 57.14 7.62 x 5.71 |
|
| 2/3” |
- - |
|
| Advanced optical specifications | ||
| Working distance range (1) | (mm) |
150 - 450 150 - 450 |
| ƒ/N |
5.6 - 32 5.6 - 32 |
|
| Back focal length | (mm) |
23.29 23.29 |
| Distortion on 1/2" (2) | (%) |
0.9 1.6 |
| Distortion on 2/3" (2) | (%) |
- - |
| Mechanical specifications | ||
| Iris control | Manual | |
| Focus control | Manual | |
| Mount | C | |
| Filter thread | M46 x 0.75 | |
| Outer diameter | (mm) | 48 |
| Length (3) | (mm) | 98.5 |
| Mass | (g) | 260 |
Last update 16 Apr 2024
Notes
- Working distance: distance between the front end of the mechanics and the object.
- Percent deviation of the real image compared to an ideal, undistorted image.
- Measured from the front end of the mechanics to the camera flange
All product specifications and data are subject to change without notice to improve reliability, functionality, design or other. Photos and pictures are for illustration purposes only.
Datasheet
Download datasheet
Layout files
DXF
IGS
STP
Despite the efforts made to generate an error-free compatibility list, we always recommend to consult the Opto Engineering® technical support department before purchasing a compatible product. Opto Engineering® shall not be liable for any damage or malfunctioning caused by the incorrect selection of a compatible product.
ITA24-GC-10C
Area scan camera 1936 x 1216 MP, Sony IMX392, CMOS Global shutter, 1/2.3", Color, 1 GigE, POE, C mount
ITA24-GM-10C
Area scan camera 1936 x 1216 MP, Sony IMX392, CMOS Global shutter, 1/2.3", Mono, 1 GigE, POE, C mount
ITA32-GM-10C
Area scan camera 2064 x 1544 MP, Sony IMX265, CMOS Global shutter, 1/1.8", Mono, 1 GigE, POE, C mount
ITA32-GC-10C
Area scan camera 2064 x 1544 MP, Sony IMX265, CMOS Global shutter, 1/1.8", Color, 1 GigE, POE, C mount
ITA51-GM-20C
Area scan camera 2472 x 2064 MP, Sony IMX547, CMOS Global shutter, 1/1.8", Mono, 1 GigE, POE, C mount
ITA51-GC-20C
Area scan camera 2472 x 2064 MP, Sony IMX547, CMOS Global shutter, 1/1.8", Color, 1 GigE, POE, C mount
