FTLP590M52

Specifications

Main optical specifications
Type long pass
Light color red
Wavelength range (nm) 595 - 1100
Cut-on 50% transmittance (1) (nm) 595
Cut-off 50% transmittance (1) (nm) -
Spectral FWHM (1) (nm) -
Mechanical specifications
Filter thread M52 x 0.75
Outer diameter (mm) 55.0
Clear aperture (mm) 47.0

Last update 05 Jul 2022

REACH

Notes

  1. Tolerance +/- 10 nm
All product specifications and data are subject to change without notice to improve reliability, functionality, design or other. Photos and pictures are for illustration purposes only.
