Main optical specifications | ||
Focal length | (mm) | 12 |
Image circle diameter | (mm) | 11.0 |
Max sensor size | 2/3″ |
Angle of view | ||
1/2" - IMX990 | (deg) | 37.8 |
2/3" | (deg) | 49.2 |
Advanced optical specifications | ||
Working distance range (2) | (m) | 0.15 - inf |
Wavelength range (3) | (nm) | 400-1700 |
ƒ/N | 1.4 - closed | |
Back focal length | (mm) | 13.1 |
Distortion on 1/2" (4) | (%) | 0.35 |
Distortion on 2/3" (4) | (%) | 0.1 |
Mechanical specifications | ||
Iris control | Manual | |
Focus control | Manual | |
Mount | C | |
Filter thread | M30.5 x 0.5 | |
Outer diameter | (mm) | 33.5 |
Length (5) | (mm) | 28.2 |
Mass | (g) | 62 |
Last update 13 Nov 2023
Notes
- Calculated at minimum object distance.
- Working distance: distance between the front end of the mechanics and the object.
- High transmittance across the wavelength range due to broadband AR coating. Designed for imaging with single wavelength narrowband illumination.
- Percent deviation of the real image compared to an ideal, undistorted image.
- Measured from the front end of the mechanics to the camera flange at infinity focus.
All product specifications and data are subject to change without notice to improve reliability, functionality, design or other. Photos and pictures are for illustration purposes only.
